The V-shaped mixer is widely used in drug manufacturing and dry powder mixing industries. It suits the uniform mixing of various powder and granular materials. Its unique V-shaped design effectively prevents material adhesion and dead corners, ensuring even mixing. Easy to operate, it enables efficient material processing and convenient cleaning. Ideal for drug making, it ensures high - precision powder mixing, meeting modern production needs and is essential in these fields.
Key attributes：
mixer type ：Planetary Mixer
barrel wolume (l)： 5-800L
material processed ：Plastics, Chemicals, Food
weight (kg) ：260 KG
voltage ：220V/380V customized
power (kw)： 750 kw
warranty ：1 Year
range of spindle speed(r.p.m)： 9-12 rp.m
material ：SUS304,SUS304L,SUS316,SUS316L,Ti
application ：Powder
place of origin ：Henan, China
Introduction:
The V mixer machine is an efficient mixing device that adopts a unique V-shaped structure. The working principle of the V-type mixer is that the motor drives the V-shaped drum to rotate, causing the materials inside to move in multiple directions—up, down, left, and right—ensuring full contact and thorough mixing. The equipment is easy to operate and clean, and it is suitable for mixing various types of raw materials. It is widely used in industries such as chemicals, food, and pharmaceuticals
Parameter：
Model | METHENA-ZPM-300 | METHENA-ZPM-500 | METHENA-ZPM-1000 | METHENA-ZPM-1500 |
Mixing bucket volume (L) | 300 | 500 | 1000 | 1500 |
Maximum loading capacity (L) | 240 | 400 | 800 | 1200 |
Maximum loading weight (kg) | 150 | 250 | 500 | 750 |
Spindle speed (rpm) | 14 | 13 | 12 | 10 |
Motor power (kw) | 1.5 | 2.2 | 4 | 5.5 |
Weight (kg) | 600 | 750 | 1200 | 1650 |
Dimensions (dynamic)(mm) | 1850*1280*1980 | 2200*1530*2220 | 2800*2000*2820 | 2930*2330*3355 |
Outstanding Mixing Uniformity: The unique V-shaped drum rotates in multiple directions, causing materials to tumble and intermix, achieving precise and uniform distribution of all materials.
Wide Material Compatibility: Whether dealing with highly flowable fine powders like flour and medicinal powder, or granular materials like plastic pellets and feed, the V mixer machine can effectively process a wide variety of materials.
Gentle Mixing: The mixing process is relatively mild, minimizing damage to the structure and shape of the material particles.
Efficient Material Processing: A large volume of material can be fully mixed in a short time, significantly improving production efficiency, meeting large-scale production needs, and reducing time costs for enterprises.
Low Residue Design: The V-shaped drum structure facilitates easy material discharge, preventing material buildup inside the drum and reducing residual amounts, thereby effectively minimizing waste.
Convenient Cleaning and Maintenance: The simple structure of the drum and overall equipment allows for easy disassembly and reassembly, facilitating deep cleaning and daily maintenance, ensuring hygienic conditions that meet the high standards required in industries like food and pharmaceuticals.
Stable and Reliable Operation: The motor and reducer work in precise coordination, ensuring a mature and stable drive system, with minimal vibration during operation, reducing the risk of equipment failure.
Good Sealing Performance: The feed and discharge ports, as well as the drive system, are excellently sealed to prevent material leakage and contamination from external impurities, ensuring the purity of the materials and the normal operation of the equipment.
Compact Space Usage: The overall structure of the V mixer machine is compact and occupies a small footprint, making it ideal for efficient space utilization in limited production environments, helping businesses save on space resources
Food Processing Industry:Baking: The V mixer gently blends dry ingredients such as flour and powdered sugar without damaging the gluten, ensuring the texture and taste of baked goods. For example, when producing cake mix, it provides convenience for consumers while maintaining consistent quality.
Seasoning Industry: It can evenly mix salt, sugar, spices, etc., ensuring consistent flavor. For example, when mixing curry powder, it allows the spices to blend thoroughly. It is also suitable for mixing nuts and dried fruits, such as when making mixed nuts or energy bars, ensuring a rich taste and even distribution of ingredients.
Pharmaceutical Manufacturing Industry:Drug Production: The V mixer is used to mix active pharmaceutical ingredients with excipients, such as fillers, lubricants, and disintegrants, ensuring uniform distribution of the drug in the dosage form and guaranteeing dosage accuracy and therapeutic consistency.
Traditional Chinese Medicine (TCM) Granule Production: It can precisely mix different herbal extract granules, meeting the combinatory requirements of traditional Chinese medicine theory and ensuring stable medicinal effects.Chemical Production Industry:The V mixer has a wide range of applications.
Pigment and Paint Production: It can mix pigment powders, fillers, resins, etc., ensuring even dispersion of the pigment, enhancing the color stability and coverage of the paint. For example, when producing latex paint, it can blend titanium dioxide with emulsion and other additives.Plastic Processing: It can mix plastic pellets with additives, ensuring consistent product quality and performance. For example, in the production of colored plastic products, it ensures even mixing of pellets with color masterbatch.
Chemical Reagent Mixing: It can achieve precise and uniform mixing of chemical reagents, providing uniform reactants for chemical reactions. For example, when preparing chemical analysis reagents, it ensures uniform mixing of powdered reagents, guaranteeing the accuracy of analysis.
Feed Production Industry:The V mixer can be used for mixing animal feed and pet food ingredients. It ensures uniform mixing of raw materials such as corn flour, soybean meal, meat powder, and cereal powder, providing balanced nutrient distribution to meet the nutritional needs of animals and pets at different growth stages. For example, when producing pig feed and cat food, it ensures that every piece of feed or cat food contains rich nutrients.
Other Application Areas:Cosmetic Ingredient Mixing: In cosmetics production, the V mixer is used to mix powdered cosmetic ingredients such as talc, kaolin, and pigments, to create products like foundation and eyeshadow. It ensures that the cosmetics have a delicate texture and even color. For example, when making loose powder, the V mixer evenly blends the powder ingredients, achieving the optimal color and texture for the product.
